Product Dimensions: 325mm x 26mm
Cable Tie Length: 100mm–650mm
Material: ABS Engineering Plastic
Surface Finish: Laser-etched serial number, screen-printed logo, and internal code
Operating Frequency: AZ-9662MHz/AZ-9610MHz
International Standards: EPC G2, ISO 18000-6C
Integrated IC Chip: ALIEN H3 Monza 4QT
Storage Capacity: EPC 96-bit, TID 64-bit, User 512-bit
Operating Temperature: -25°C to +65°C
Storage Temperature: -35°C to +70°C
Data Retention: >10 years
Erasure Cycles: 100,000 times
Reading Distance: 0–8 mm (Reading distance depends on the operating environment and the reader)
Applications: Freight logistics management, parcel distribution management, warehouse management, inventory tracking and management
Inspection Standard: 100% fully inspected before shipment
Type: Self-locking cable tie
Packaging: 100 pieces per bundle
Description
RFID cable tie tags are widely used in various applications where items need to be secured. The electronic tag on the cable tie is positioned on the outside of the bundle, making it unaffected by the material of the item being secured and allowing it to be easily attached to specific locations on the item. These tags enable contactless identification and rapid authentication of secured items, facilitating the management of item data and supporting logistics tracking requirements.
Features
● Enhanced industrial ABS plastic for greater durability
This cable tie tag is manufactured using modified industrial ABS plastic, epoxy resin encapsulation, and ultrasonic welding. It offers excellent corrosion resistance, UV protection, and waterproofing. The product features a self-locking mechanism with tamper-proof functionality and a reliable structure.
● High Sensitivity
Faster and more stable data read/write performance. The built-in inlay antenna utilizes pre-exposure, development, and etching technology, with aluminum etched line widths controlled within ±0.03mm and the finest lines reaching 0.075mm. The antenna lines are smooth with minimal tolerance between line spacing and width, resulting in a more precise resonance frequency and faster, more stable data read/write operations.
● Adaptable to Complex Environments
Equipped with built-in metal locking teeth, the robust design withstands various challenging conditions (extreme temperatures, tear resistance, and use around marked objects).
● Water- and Dust-Resistant
Highly sealed for versatile environments. Utilizing ultrasonic sealing technology, it maintains a strong seal and can be used in humid or sandy conditions. When necessary, it achieves an IP68 waterproof rating, enabling long-term use in harsh environments.
● Easy Installation
The “pull-to-lock” design allows for manual sealing. Simply pull gently to secure the tie, and the reliable structure features tamper-proof functionality.
● Wide Range of Applications
RFID cable tie tags for item traceability and anti-counterfeiting are widely used in airline baggage tracking, food logistics, asset management, container sealing, express parcels, logistics management, and power cable classification management.
Application
1. Freight logistics management and parcel circulation management.
2. Warehouse management and inventory tracking.
3. Airline baggage tracking.
4. Container sealing.
5. Asset management on metal surfaces with limited installation space, etc.
